The modular assembly solution incorporates the ULTIMA Connect pit system, engineered ULTIMA beams and an interconnecting precast concrete base slab and encasement for rapid installation. This system provides a significantly faster installation than conventional alternatives, providing substantial cost reductions for the installer.
Features & benefits
Fast and easy to install
Customisable to suit your install needs
STAKKAbox™ ULTIMA Hybrid can be used to construct virtually any conceivable access pit clear opening. ULTIMA offers a huge range of pit dimensions thanks to a large number of standard sections.
Flat Pack Option
STAKKAbox™ ULTIMA Hybrid systems can be sent to the site in a ‘flat pack’ arrangement, allowing for flexibility in delivery and installation. An extensive pit system can be reduced to several pallets rather than occupying an entire truck, reducing total freight costs.
Glass-reinforced plastic (GRP), is a composite material, fibre-reinforced polymer made of a plastic reinforced by fine fibres made of glass. GRP has a high strength to weight ratio, high-temperature range, high mechanical properties and is fire retardant. Additionally, GRP is also chemically inert and isn’t susceptible to creep.
STAKKAbox™ ULTIMA Hybrid is suitable for installation in environments rated to Class D load rating (ultimate limit state design of 240kN) under the Australian Standard AS/NZ 3996.
